SIRIO 6 COLORS - REEL TO REEL

The Sirio Flexo printers are developed for medium long runs, with printing jobs one side: 6+0 and “front reverse” 3+3 -4+2 – 5 for the 6 Col. Printer and 4+0 and "Front - Reverse" 2+2 - 3+1for the 4th Color printer.

They are concepted with the printing groups of our central drum machines this guaranting an optimum technical level combined to the mechanical solidity.
These models are designed for the printing process of different materials as LDPE, HDPE, PP, PVC film or tubolar.
The mechanical structure is configurated with all printing groupes perfectly horizontal.and all machines are prepared for printing with solvent or-water based inks. Max mechanical speed is around 200 mt/min.
ACCESSORIES AND OPTIONALS

These printers according to the specific applications, can be provided with the following accessories:

  • Automatic edge guide before printing stations
  • Hoist for changing and loading printing cylinders
  • Heating system by gas
  • Automatic edge guide before re-winding stations
  • Pneumatic pumps for ink
  • Viscosimeter system
  • Videocamera for printing process control
  • Chambered doctor blades
  • Unwinder & Rewinder fully automatic Revolver
TECHNICAL DETAILS
TECHNICAL DETAILS
Material passage:
1050 mm
Maximum printing width:
1000 mm
Minimum printing lenght:
300 mm
Maximum printing repeat lenght:
1100 mm
Mechanical speed max:
200 m/min
TECHNICAL DETAILS
Material passage:
1250 mm
Maximum printing width:
1200 mm
Minimum printing lenght:
300 mm
Maximum printing repeat lenght:
1100 mm
Mechanical speed max:
200 m/min
TECHNICAL DETAILS
Material passage:
1450 mm
Maximum printing width:
1400 mm
Minimum printing lenght:
300 mm
Maximum printing repeat lenght:
1100 mm
Mechanical speed max:
200 m/min
TECHNICAL DETAILS
Material passage:
1650 mm
Maximum printing width:
1600 mm
Minimum printing lenght:
300 mm
Maximum printing repeat lenght:
1100 mm
Mechanical speed max:
200 m/min
